Description
FMC003 is a small plug and play device with LTE CAT 1 network coverage including 2G (GSM) fallback compatibility.
Main feature of FMC003 is its possibility to read OEM parameters (PIDs) via OBD port. With this device you will be able
to read Real Odometer and Real Fuel Level data. More to that, device comes with supported vehicles and data list, so
you do not need to guess no more, now you know what data can be read from a specific vehicle. It is a perfect tracker
for a wide range of use cases – including fleet management of light commercial vehicles, driver log-book, insurance
telematics (UBI), car rental & leasing and others. Device supports various Bluetooth® LE 4.0 features including sensors,
beacons, firmware and configuration update via Bluetooth® which expands its already rich set of features.
| Module | |
| Name | Teltonika TM2500, MeiG SLM320-E, MeiG SLM320-LA |
| Technology | LTE(CaT1)/2G(GSM/GPRS)/GNSS/BLUETOOTH® LE |
| GNSS | |
| GNSS | GPS, GLONASS, GALILEO, BEIDOU, QZSS, DGPS, AGPS |
| Receiver | 33 tracking channel |
| 99 acquisition channel | |
| Tracking sensitivity | -165 dBM |
| Position Accuracy | < 2.5 m CEP |
| Velocity Accuracy | < 0.1 m/s (within +/- 15% error) |
| Hot start | < 1 s |
| Warm start | < 25 s |
| Cold start | < 35 s |
| Cellular | |
| Technology | LTE Cat 1, GSM |
| 2G bands | GSM: B2/B3/B5/B8 |
| 4G LTE bands | SLM320-E: LTE FDD: B1/B3/B7/B8/B20/B28 LTE-TDD:B38/B40/B41 SLM320-LA: LTE FDD: B1/B2/B3/B4/B5/B7/B8/B20/B28 LTE-TDD:B40 |
| Data transfer | LTE:LTE FDD: Max 10Mbps (DL)/Max 5Mbps (UL) |
| LTE TDD: Max 8Mbps (DL)/Max 2Mbps (UL) | |
| GSM:GPRS: Max 85.6Kbps (DL)/Max 85.6Kbps (UL) | |
| Data support | SMS (text/data) |
| Transmit power | Class 4 for GSM850/900: 23±2dBm |
| Class 1 for GSM1800/1900: 20±2dBm | |
| Class 3 for LTE-TDD: 23±2.7dBm | |
| Class 3 for LTE-FDD: 23±2.7dBm | |
| Power | |
| Input voltage range | 10-30 V DC with overvoltage protection |
| Internal Back-up battery | 170 mAh Li-Ion battery, 3.7 V (0.63 Wh) |
| Internal fuse | 3A, 125V |
| Power consumption | At 12V < 250 mA Max. (with full Load / Peak): |
| At 12V < 3 mA (Ultra Deep Sleep) | |
| At 12V < 5 mA (Deep Sleep) | |
| At 12V < 16 mA (Online Deep Sleep) | |
| At 12V < 18 mA (GPS Sleep) | |
| At 12V < 33 mA (nominal with no load) | |
| At 12V < 2A Max. (with full Load / Peak) | |
| Bluetooth® Technology | |
| Specification | 4.0 + LE |
| Supported peripherals | Temperature and Humidity sensor, Inateck Barcode Scanner, Universal Bluetooth® LE sensors support |
| Physical specification | |
| Dimensions | 67,2 x 49,6 x 25 mm (L x W x H) |
| Weight | 63 g |
| Operating environment | |
| Operating temperature (without battery) | -40 °C to +85 °C |
| Storage temperature (without battery) | -40 °C to +85 °C |
| Operating humidity | 5% to 95% non-condensing |
| Ingress Protection Rating | IP41 |
| Battery charge temperature | 0 °C to +45 °C |
| Battery discharge temperature | -20 °C to +60 °C |
| Battery storage temperature | -20 °C to +45 °C for 1 month |
| -20 °C to +35 °C for 6 months | |
| OBD interface | |
| Data | HS CAN, MS CAN, SW CAN, K-line |
| Data reading | OEM Fuel level, odometer and up to 32 vehicle onboard parameters, supported OBD protocols: |
| ISO 9141-2 (5 baud init, 10.4 kbaud) | |
| ISO 14230-4 KWP (5 baud init, 10.4 kbaud) | |
| ISO 14230-4 KWP (fast init, 10.4 kbaud) | |
| ISO 15765-4 CAN (11 bit ID, 250 kbaud) | |
| ISO 15765-4 CAN (11 bit ID, 500 kbaud) | |
| ISO 15765-4 CAN (29 bit ID, 250 kbaud) | |
| ISO 15765-4 CAN (29 bit ID, 500 kbaud) | |
| ISO 14229 (UDS) | |
| J2819 (VW TP2.0) | |
| Interface | |
| Connection | OBDII Socket |
| GNSS antenna | Internal High Gain |
| Cellular antenna | Internal High Gain |
| USB | 2.0 Micro-USB |
| LED indication | 2 status LED lights |
| SIM | Micro-SIM or eSIM |
| Memory | 128MB internal flash memory |
| Features | |
| Sensors | Accelerometer |
| Scenarios | Green Driving, Over Speeding detection, Jamming detection, GNSS Fuel Counter, Excessive Idling detection, Unplug detection, Towing detection, Crash detection, Auto Geofence, Manual Geofence, Trip |
| Sleep modes | GPS Sleep, Online Deep Sleep, Deep Sleep, Ultra Deep Sleep |
| Configuration and firmware update | FOTA Web, FOTA, Teltonika Configurator (USB, Bluetooth®) |
| SMS | Configuration, Events, Debug |
| GPRS commands | Configuration, Debug |
| Time Synchronization | GNSS, NITZ, NTP |
| Fuel monitoring | OBDII, OEM fuel level |
| Ignition detection | Accelerometer, External Power Voltage, Engine RPM |
| Certification & approvals | |
| Regulatory | CE/RED, UKCA, E-Mark, EAC, RoHS, REACH, CITC, Anatel, RCM, SDPPI POSTEL, SIRIM QAS |
